Highlights:
Supports the battery mode or non-battery mode.
Non-battery mode: charging with solar (Main) and utility (Assist) simultaneously.
Surge and reverse connection protections to support the lithium battery system perfectly.
Three charging modes: Solar only, Solar priority, Utility & Solar.
Two AC output modes: Utility priority and Inverter priority.
High tracking efficiency of MPPT no less than 99.5%.
PFC technology achieves a high power factor of AC to DC charging and reduces grid capacity usage. Advanced SPWM technology and pure sine wave output.
Customized charging current and discharging limited current.
SOC with the self-learning feature is visible on LCD.
4.2 inch LCD to monitor and modify system parameters.
Optional WiFi or GPRS Remote control by the RS485 isolated communication port.
Optional BMS-Link port, which takes the charging and discharging control from BMS.
Specification
|
Item
|
UP2000-HM6021
|
UP3000-HM10021
|
UP3000-HM5041
|
UP3000-HM8041
|
|
Rated battery voltage
|
24VDC
|
48VDC
|
|
Battery input voltage
|
21.6~32VDC
|
43.2~64VDC
|
|
Max. battery charging current
|
60A
|
100A
|
50A
|
80A
|
|
Inverter output
|
|
Continuous output power
|
2000W
|
3000W
|
3000W
|
3000W
|
|
Max. surge power(3S)
|
4000W
|
6000W
|
6000W
|
6000W
|
|
Output voltage range
|
110VAC(-3%~+3%), 120VAC(-10%~+3%)
|
|
Output frequency
|
50/60±0.2%
|
|
Output wave
|
Pure Sine Wave
|
|
Load power factor
|
0.2-1(Load power ≤ Continuous output power)
|
|
Distortion THD
|
THD≤5%(Resistive load)
|
|
80% rated output efficiency
|
89%
|
90%
|
91%
|
91%
|
|
Max. Rated output efficiency
|
88%
|
88%
|
90%
|
90%
|
|
Max. output efficiency
|
90%
|
92%
|
92%
|
92%
|
|
Switch time
|
10ms(Switch from the utility output to the inverter output), 15ms(Switch from the inverter output to the utility output)
|
|
Utility charging
|
|
Utility input voltage
|
88VAC~132VAC (Default), 80VAC~140VAC(Programmable)
|
|
Utility input frequency
|
40~65Hz
|
|
Max. utility charge current
|
60A
|
80A
|
40A
|
40A
|
|
Solar charging
|
|
Max. PV open circuit voltage
|
250V(At minimum operating environment temperature), 220V(At 25℃ environment temperature)
|
|
MPPT voltage range
|
60~200V
|
|
Max. PV input power
|
2000W
|
3000W
|
3000W
|
4000W
|
|
(Note: For the curve of Max. PV input power Vs. PV open-circuit voltage, see chapter 3.4 Operating mode for details.)
|
|
Max. PV charging power
|
1725W
|
2875W
|
2875W
|
4000W
|
|
Max. PV charging current
|
60A
|
100A
|
50A
|
80A
|
|
Equalize charging voltage
|
29.2V(AGM default)
|
58.4V(AGM default)
|
|
Boost charging voltage
|
28.8V(AGM default)
|
57.6V(AGM default)
|
|
Float charging voltage
|
27.6V(AGM default)
|
55.2V(AGM default)
|
|
Low voltage disconnect voltage
|
21.6V(AGM default)
|
43.2V(AGM default)
|
|
Tracking efficiency
|
≥99.5%
|
|
Temp. compensate coefficient
|
-3mV/℃/2V(Default)
|
|
General
|
|
Surge current
|
50A
|
60A
|
56A
|
95A
|
|
Zero load consumption
|
<1.6A
|
<1.6A
|
<1.2A
|
<0.8A
|
|
(without PV and utility connection, turn on the load output)
|
|
Standby current
|
<1.2A
|
<1.0A
|
<0.7A
|
<0.6A
|
|
(without PV and utility connection, turn off the load output)
|
|
Mechanical Parameters
|
|
Dimension(H x W x D)
|
607.5x381.6x127mm
|
642.5x381.6x149mm
|
642.5x381.6x149mm
|
642.5x381.6x149mm
|
|
Mounting size
|
585*300mm
|
620*300mm
|
620*300mm
|
620*300mm
|
|
Mounting hole size
|
Φ10mm
|
Φ10mm
|
Φ10mm
|
Φ10mm
|
|
Net Weight
|
15kg
|
19kg
|
19kg
|
19kg
|
|
Enclosure
|
IP30
|
|
Relative humidity
|
< 95% (N.C.)
|
|
Environment temperature
|
-20℃~50℃
|
